Structure - System description SVCN

Comfort/half cylinder

In the case of the SI Digital Cylinder AX (Comfort and half cylinder), all electronics are located on the outside.

  • Control Unit (CU)
  • Card Reader (CR)
  • Batteries
  • Secure element (SE) - in the profile core on the outer side

Freely rotating

In the case of the SI Digital Cylinder AX (freely rotating), each of the two reader thumb-turns is equipped with complete electronics.

  • Control Unit (CU)
  • Card Reader (CR)
  • Batteries
  • Secure element (SE) - in the profile core on the outer side

NOTE

notice

Electronics for SI Digital Cylinder AX with reader on both sides

In the version with a reader on both sides, the SI Digital Cylinder AX is equipped with an electronic reader thumb-turn on the outside and an electronic reader thumb-turn on the inside. Both thumb-turns are independent of each other.

  1. Create and configure the two electronic reader thumb-turns separately.
  2. Program the two electronic reader thumb-turns separately.

Length modularity

The Euro Profile variant is modular and can be extended, shortened or otherwise adapted on site. See the length modularity manual for details.
