Installing the Glass Door Cylinder AX - System description SVCN

  1. 1.5 mm hexagonal wrench available.
  2. PH2 screwdriver at hand.
  1. Undo the grub screw from the inside thumb-turn (SW 1.5 mm).
  3. Twist the inside thumb-turn off anti-clockwise.
  5. Insert the SI Digital Glass Door Cylinder AX into the door.
  7. Secure the SI Digital Glass Door Cylinder AX firmly into place with the fastening screw (PH2).
  9. Screw the inside thumb-turn clockwise back onto the SI Digital Glass Door Cylinder AX.
  11. Secure the inside thumb-turn with the grub screw (SW 1.5 mm).
  1. SI Digital Glass Door Cylinder AX is installed.
